YACHT DESIGN. YACHT BUILDING MOTOR YACHTS; CRUISING HOUSE BOATS ; YACHT PRODUCTION TECHNOLOGIES ; ROMANIA; CHINA. Our custom yachts are as per owner requirements Lloyds Certified or Lloyds Certification compliant; EU RCD certified or EU certification compliant; comply with the European Recreational Craft Directive /ISO Standards. At left a series of links to Recreational Craft Directive related sites. Or company based in Bucharest Romania draws from over 12 years yacht building experience; has delivered various types of boats yachts and yacht production and design related services globally as far as Americas; Africa; China; Hong Kong; since 1997. We work globally with yards and manufacturing shops in China , Romania, India, to deliver value for the customer upper scale quality fine solid yachts and boats both sail and motor up to 100 ft (30 m); 70-100 tons Displacement; To meet the ever increasing demand for new YACHT and BOAT Designs for series production or individual projects we are pleased to offer our MOTOR BOAT and MOTOR YACHT designs and design packages. These ready for building design packages represent a valuable opportunity to any yacht manufacturing company or individual, seriously interested in having built a high quality Cruising YACHT at reasonable costs. We Deliver Cost Efficient Custom Building of our Motor Yachts Designs as well as the Custom Building of a wide choice of International Designs.: "Xplore 62" ft Motor Yacht Design -A.Rochian We Custom produce this Motor Yachts These yachts are to be delivered as per Owner order FOB Hong Kong; FOB Constanta. Construction Composite. Flybridge Swim Platform Dinghy garage Bowthruster Sternthruster Lifting stern platform Hydraulic Hydraulic steering CLASS B *Passengers berths:8 /One Master Compartment;2 Guest cabins; One Crew cabin. *Max capacity 30 pers. *LOD .........19.00m *Beam .......6.00 m *Draft .........0.9m *Weight.......50tons *LWL...........17.3m *Propulsion..2x800hp Diesel Caterpillar *Fuel .......3000liters *Speed...... 24-35 knots SPECIFICATIONS(To be final by Owner) Construction • Solid glass for hull bottom • "Vacuum infused fiberglass lamination with Core-Cell PVC foam core and of different E-glass reinforcements in topside, deck and fly" • Vinyl ester barrier hull laminate (3 layers) for osmosis protection • PVC foam cored bulkheads • Hull to deck connection mechanically fastened and bonded • "Ashland" gel-coat surface finish • Bottom paint: 2 prime coats of "International" Micron CSC, 3 top coats of Gelshield Deck Equipment • 316L grade stainless steel hang rails, high gloss mirror finish • 1 x "Lewmar" vertical Windlass, 24VDC, dual direction, two stations • 45kgs "Lewmar" Delta polished SS anchor • SS316L anchor roller/chock • SS316L fairleads/scuppers • SS316L chafe plate on bow • 53mm-35mm oval shape SS316L exterior hand rails w/38mm Supports • 6 x 12” SS cleats • SS316 deluxe swim ladder • SS flag staff and sockets, bow and stern • 24 VDC waterproof deck lights • "Whale" fresh water wash down: fore, aft Mechanical Systems & Engine Room • "2 x ""Caterpillar"" C12 660HP diesel engines w/ 60A alternators and ZF325A transmissions, electronic control with 2 helm stations, standard engine manufacturer instrumentation, " • "Teleflex" power steering systems (with valves for autopilot option) • "1 x ""Onan"" 20kw generator with sound shield and remote control manufacturer's standard instrumentation" • Oversized FRP Wet Mufflers for main engines and generator(s) • "Racor" dual fuel filters for each engines and generator(s) • 2 x 2000L welded aluminum 5052 fuel tanks with vents, sight gauge. • "Wema" Tank Gauges for fuel, fresh water, black water, and grey water tanks • Fuel management system with transfer pump • 1 x 1,000L integral fresh water tank with vents • 1 x "Head Hunter" Fresh Water System w/pressure tank • 1 x "Torrid" 220VAC, 60L, Water Heater w/connection to engine heat exchanger • 1 x 300L SS Black Water Holding Tank with high level alarm and "Y" valve selector • "Headhunter" macerator pump • 1 x 180L SS Grey Water Tank with "Headhunter" pump • PEX piping with suitable fittings for all water systems • 3 x "Rule" automatic bilge pumps with float switches and alarms. • Seacocks on all through-hull fittings with double hose clamps • Bronze Water Strainers for all raw water intakes • "Jabsco" hand emergency bilge pump located in the cockpit • SS316 Rudder Blades and Stocks • Aquamet 17 Propeller Shafts • Cast bronze Shaft Struts • Dynamically balanced 4-blade Nibral propellers • "Bennett" 40" Trim Tabs • Engine room ventilation systems with intake air blowers and baffled air inlets • """Sea Fire"" fire protection with automatic and manual actuation and alarming, consisting function of automatic shut down of engines, generators, E/R blower and air inlets." • "Engine room insulated with specially designed putty, aluminum sheets and foam, covered with perforated aluminum sheets" Electrical System • 220VAC and 24/12 VDC Electric Distribution Panels w/ "Carling" circuit breakers • "Cruise Air" 40,000 BTU Split Type Air Conditioning System • "Vision" 4 x 230AH deep cycle batteries for house • "Vision" 2 x 230AH AGM batteries for engine start • "Vision" 2 x 230AH AGM batteries for windlass and bow thruster • 1 x 60A "Victron" charger for house batteries • 1 x 30A "Victron" charger for windlass batteries • 1 x 4kw "Victron" inverter/charger • 1 x "Marinco" 50A, 110V/220V Shore Power supply • All wires are marine-grade, tinned and color coded, bundled in PVC pipes • "Bonding system connecting generator, all through-hulls and main metal components to transom zinc anodes" • "Blue Sea" Generator/shore power selector switch and shore power polarity indicator • "Boat alarming system for low oil pressure and high temperature in generator, high bilge level,smoke detectors (in all rooms)." • 5 x "Aqua Signal" navigation lights • 24VDC Halogen overhead light fixtures throughout • 24VDC LED rope lighting for valance and floor • 24VDC step lighting • 24VDC reading lights • 4 x 220VAC fluorescent engine-room overhead lights • All sockets are from "Vimar" • Automatic wardrobe lights Fly Bridge • Two-piece Plexiglass windshield with SS frames • Fiberglass molded instrument and electronic console • Custom SS steering wheel • 1 x "Todd" helm seat, low back Admiral, medium pedestal, foot-rest • SS rails around aft bridge • Fiberglass lounge seat with upholstered cushions, storage under • SS sink with cold water faucet • Fiberglass molded radar arch • Fiberglass hatch covering stairs to galley, with SS hand rail • Hatch and ladder to aft deck • Drain system • 1 x "Marco" dual air horn Fore Deck • Anchor locker hatch with pneumatic lift • 12mm Teak deck • Forward sun pads, plus round hatch to VIP stateroom • Foredeck molded seat with upholstered cushions • 2-piece tinted and tempered glass windshield with glass glued to fiberglass frame recesses • "Imtra" windshield wipers with fresh water wash system • "Lemar" transparent hatch • FRP storage for fenders, cushions, etc. Cockpit • Extended swimming platform covered with teak • SS 316 swimming ladder • Molded fiberglass stairs covered with teak to swimming platform • Molded fiberglass seats with upholstered cushions • Transom shower kit in cabinet • Hinged tempered glass doors to swimming platform General Interior • "All interior furniture made from plastic honeycomb cored sandwich panels covered by veneers of customer's choice with solid wood corners. Customized gloss varnish " • Cabin soles finished for customer's carpets; wood planked floor in galley only • Overhead and part of walls are upholstered with leather or vinyl • "Raseto & Casereto" door handles and locks • All door hinges are from "Sugitsune" • All carboard hinges are from "Hafele" • Drawers and cabients finished with "FORMICA" and include guides and stops • Customized marble countertops at galley and heads Salon • Sofa with customized leather • "L" shape settees with drawers under • Upholstered ceiling and wall, with customzied leather • Customized helm console • 1 x "Todd" chair • Aluminum framed aft salon door Galley & Dinette • "L" shaped countertops and overhead cabinets • Microwave oven • "Isotherm" Refrigerater • "Bosch" dishwasher • Faucet with removable sprayer handle • Ceiling, under cabinet lighting • Electro-magnetic cook top • Smoke detector • Electricity outlets Master Stateroom & Head • Queen berth with storage under • SS framed tinted, tempered glass opening port lights • Port side cherry veneered vanity with stool • Ceiling, valance, floor, reading lights • TV cabinet • Phone jack • Book shelves • Finished floor for carpet • "Tecma" electric head with fresh water flush • Customized marble countertop with SS sink • Mirrored medicine cabinet • "Franke" Faucets and bath accessories • "Jabsco" head fan • Smoke detector • Electricity outlets Forward VIP Room & Head • Queen berth with storage under • Berth side cabinets • Wardrobe with cedar lining • Ceiling, valance, reading lights • TV holder • SS port lights, port and starboard • Finished floor for carpet • Phone jack • "Tecma" electric head with fresh water flush • SS port light, starboard • Customized countertop with SS sink • Mirrored medicine cabinet • Integrated fiberglass molded shower stall with mirror overhead • "Franke" Faucets and bath accessories • "Jasco" head fan PRICE by Request "Black Sea Cruiser36" Design- A.Rochian Fiberglass Composite. Flybridge Bowthruster Teak interior Steering Hydraulic Pressure water Hot Water Air Conditioning;Heating Sys. Hull composite Swim Platform Windlass elecric CLASS B *Passengers berths:5 *Max capacity 10 pers. *LOD .........11.00m *Beam .......3.500 m *Draft .........1.0m *Weight.......9.3tons *LWL...........10.3m *Propulsion..2x230hp Diesel *Fuel .......600liters *Speed...... 34 knots PRICE by Request "X-PLORE" Fast Motor Boat 33 ft Design -A.Rochian Construction wood/epoxy /mahogany Hull Wood&Epoxy Sleeps 3 Cuddy Cabin Enclosed shower Pressurised water TV Double bed Upholsered deck lounge Swim Platform Trim Tabs Hydraulic Hydraulic Steering Bowthruster Extra large Fuel tanks Sun Deck *Sleeps:3-4 *LOA .........10.00 m *Beam .......3.30 m *Draft...........0.5m *Weight.......6500 kg *Prop........ Optional 1x 150; 2x250 hp Gas/Diesel *Speed...... 35 knots PRICE by Request "X-PLORE Center Console 30" Sport Fishing Boat 30 ft Design -A.Rochian Fiberglass composite *Passengers capacity:6 *LOD .........9.00 m *Beam .......3.00 m *Draft...........0.3m *Weight.......35000 kg *Prop........ 2x200 hp Suzuki *Fuel .......200liters *Speed...... 30 knots "BLACK SEA CRUISER 27" Sports Fishing Yacht Design- A.Rochian •This is a motor yacht hand crafted uniquely for his Owner. Every part and detail is manufactured with utmost care and attention. The lifespan and Strenght of this boat 25mm thick hull bottom is much higher than Series Boats. Boat is Trailerable on twin axle Trailer. I designed the "Black Sea Cruiser 27" Hull lines based on American East Coast Lobster Boats, a seaworthy and FUEL ECONOMIC boat. This was the first and only boat designed and built in Romania to be exported to America. The American lobsterboat hull has heavy displacement; fine entry, flared Fwd topsides for dry ride; a massive deep keel for stability. ; handles well big waves,the large propeller makes for economic behavior at low and moderate speeds, the large rudder and Vetus BowThruster make excellent manoeuvrability. The boat may be equipped with one STEYR 212 hp Turbo Injection Diesel, 125 hp Diesel or 2x120 hp Diesels. The Black Sea Cruiser27 offers confortable fishing&cruising accomodations for 4-6 persons Enclosed wc & head wth pressurised water shower, propane stainless stove and icebox at galley ; pilot and copilot adjustable upholstered armchairs. *RCD category B/Offshore(designed for offshore voyages /wind force 8,wave heights>4m) *LOD:27 ft / 8.25m *LWL: 25.2 ft/ 7.80m *Breath:9.8 ft/ 3m *Displacement:cca 3000 kg *Draft:3'/ 0.92m *Hard chined lobster boat hull design for economic fuel consumption and good sea keeping performance. *Fine entry for speed. *Flare forward for dryness. *Long keel protecting the propeller/hull. BUILT BOTTOM : solid laminate 20mm thick, TOPSIDES: solid laminate 12mm KEEL: solid laminate 28 mm thick this makes for an excellent TRANSVERSE STABILITY (weight down) DECK&CABIN: *SANDWICH Fiberglass&Herex PVC foam core. *Antiskid *Mahogany varnished Handrais *SS engine air intakes *Mahogany varnished Mast top cabin GALLEY *Stainless 2-3 burners stove. *Stainless sink *Fresh water tank 100 l *Pressurised water system *Galley at cockpit converts into Cokpit Seating *Stainless 2 burners stove&Sink Box pulls in and out under the Side deck(STB). *Teak Stove Cover Converts into Cockpit Chair *ICE Box pulls in and out under the Side deck.(Port) *Ice Box Cover Converts into Cockpit Chair *Fresh water tank 100 l *Pressurised water system INTERIOR *Standard layout Twin berth cabin allows sleeping for 4 pers(the twin berths joining) *Twin cabinets mahogany louvered doors *Reading Lights at each berth *Depositing space under berths. *Mattresses. *Removable teak cabin Sole *Mahogany FWD compartment Door *Marine polished doors hardware *Enclosed Forward wc & head with pressurised water ;shower, *4 Moonlight Aluminium Anodised Ports; opening PILOT CABIN *Twin Pilot upholstered armchairs. *Lateral Pilot cabin windows opening *Mahogany Copilot coffee charts table. *Raised, molded bridgedeck over engine, fuel and battery compartment with lock-down access hatches. POWER: *Diesel Turbo Injection *STEYR MO236K43/ inboard / 214 hp. *4300 rpm/300kg *4 blade Propeller VETUS *2 Stainless Diesel tanks/ 150 l each *tachometer *hourmeter *water temperature *oil pressure *alarms(audible and visible) STEERING *Steering Wheel Chrome S/S *Morse teleflex Steering mechanism(optional Hydraulic) *Large Rudder Blade *Optional Bowthruster (Vetus) VENTILATION *Moonlight opening hatch ports with screens *Cockpit sole panels removable for bilge inspection *Optional cuddy cabin Large Aluminum opening hatch ELECTRICAL SYSTEM *2x75 Ah batteries *light in cabin *Reading lights berths *Light engine room *electric fan engine room *8 breakers panel *2 electrical Bilge pumps *Boat horn SHOWER WC Compartment (Forward) *WC ; manual pump *Waste tank *Ventilation *Shower pressurized. *Sink, *foot pump, *faucet, *mirror *cabinet PRICE by Request YACHT DESIGN & YACHT PRODUCTION Guangzhou ; Hong Kong; CHINA. Images from our partner yacht production facilities China; 2009-1010. By most accounts mainland China's economy has grown 8-10% anually in recent years. The China Boat Show edition 2010 Shanghai had cca 300 attending corporations; a very substantial network of suppiers is serving the Yacht production and building trade. Some of the most up to date Composite Production and Boat design and building techniques and technologies are currently being developed in China. Guangdong Province has emerged in recent years as one a rapidly developing global manufacturing hub. We provide consultancy services related to yacht design and production bringing to yacht manufacturing companies our technological,practical and organisational solutions aimed at lowering costs and maximising efficiency. Through direct working with local engineering team and hands-on office and production floor work; we help build better quality more efficiently in the 60-90 ft range. Consultancy re setting up of boat production factory in Guangzhou China ;as illustrated at right of page; comprises setting up a correct set of moulds for series boat production; correcting existing molds; design and building of new moulds; design and building rotating and lifting equipment for the handling of moulds; design and organising of series production lines; procurement of equipments and materials and setting up of the purchase department ; setting up of human resources department and outsource bring in necessary human resource;training existing employees; transfering know how re boat and composites manufacturing process. detail designing of motor boats to be produced; training existing employees; We offer consultancy on EU Recreational Craft Directive compliance and certification of new yacht design and production according to RCD and ISO 12215-1-8. We do the structural design of large yachts according to ISO 12215(1-8) and the documentation package required in the certification process.
Custom Search DRAWINGS AND ILLUSTRATIONS ON THIS PAGE ARE L&A Maritime SRL Property. Please do not copy ; do not use for commercial purposes ; do not reproduce without L&A Maritime SRL and Mr Rochian Andrei Specific writen approval. To protect our copyright our drawings and illustrations are on purpose not accurate representations of the actual design or craft. |
|||
